AirGate-Modbus Wireless Units for Rs485 Modbus network

  • Point to Point or MultiPoint
  • Mesh Network
  • Same device Receiver - Transmitter - Repeater


Model AirGate-Modbus
Serial Port Rs485
Protocol Modbus
Wireless Specifications 2,4 GHz, 15 channels
Distance 1 km (open area)
Transfer side

You can cnfigure as Receiver (Master side) or Transmitter (Slave side)

it is Mesh Network topolgy.

Secure and trusted communication

Power Supply 10...30 Vdc
Mounting DIN Rail

PC Software in connection of USB

(Configuration software is free)
