DigiRail OEE Smart IO Module





Versions DigiRail-OEE-ETH DigiRail-OEE-WRL
Pictures
Analog Inputs (AI)

2 Channels

  • 0-20 mA, 4-20 mA, 0-5 Vdc, 0-10 Vdc
  • 15 bit çözünürlük

2 Channels

  • 0-20 mA, 4-20 mA, 0-5 Vdc, 0-10 Vdc
  • 15 bit çözünürlük
Digital Inputs (DI)

6 Channels

  • max 30 Vdc trigger
    (Lojik 0 = < 0,5 V   -   Lojik 1 = > 3 V)

  • Counter function
    (Dry contact = < 10 Hz, PNP = 3kHz, NPN = 3kHz)

6 Channels

  • max 30 Vdc trigger
    (Lojik 0 = < 0,5 V   -   Lojik 1 = > 3 V)

  • Counter function
    (Dry contact = < 10 Hz, PNP = 3kHz, NPN = 3kHz)
Digital Outputs (DO)

2 channels

  • NPN
  • max 700 mA

2 channels

  • NPN
  • max 700 mA


Datalogger

(Buffer Capacity)

7000 record

(total)

7000 record

(total)

Serial Port

1 x Rs485

  • Rs485 / Ethernet Modbus converter

1 x Rs485

  • Rs485 / Ethernet Modbus converter

Ethernet

(and Protocols)

1 x Ethernet

  • Modbus TCP/IP Server
  • MQTT

Yok

Wifi

(and Protocols)

Yok

Wi-Fi

  • Modbus TCP/IP Server
  • MQTT

Power

10...30 Vdc

10...30 Vdc

Working Temperature

-20...+60 ºC

-20...+60 ºC

Dimension

129x142x38 mm

129x142x38 mm

Mounting

Din Rail and Wall Mount

Din Rail and Wall Mount
